Description
Specifications
-
Material: Heavy-duty metal tank
-
Reservoir Capacity: 20 quarts (steel reservoir)
-
Operation Type: Double-acting (Power-Up / Power-Down)
-
Maximum Pressure: 3200 PSI relief setting on A port; 1500 PSI on B port
-
Motor: 12V DC, 1.6 kW
-
Flow Rate: Up to 0.91 GPM
-
Port Size: SAE #6 port, horizontal mount
-
Control: Handheld pendant with 15 ft (4.5 m) removable cord
Features
Exceptional Durability
Constructed with high-strength, corrosion-resistant materials, this hydraulic pump is designed to withstand heavy use and harsh conditions, ensuring long-lasting performance and reliability.
Powerful Double-Acting Design
Equipped with a 12V, 1.6 kW DC motor, this pump provides strong lifting and lowering capabilities, achieving a high flow rate of up to 0.91 GPM for efficient operation.
High Efficiency & Reliable Start
The hydraulic unit starts quickly and delivers smooth, consistent oil flow when correctly connected to the power source. Its double-acting functionality ensures efficient lifting and controlled lowering, ideal for demanding hydraulic applications.
Optimized Performance
Features a 20-quart steel reservoir, SAE #6 port connector, and a robust 3200 PSI relief setting for maximum lifting power. The included 15 ft remote pendant allows for safe, convenient control from a distance.
Versatile Applications
Perfect for any hydraulic system requiring cylinder extension or retraction. Commonly used in dump trailers, scissor lifts, truck tailgate lifts, snowplows, aerial platforms, material handling systems, road signage lifts, and wheelchair lifts.
